It mainly shovels, loads, unloads and transports bulk materials like soil and stones. It also conducts light excavation on rocks and hard soil. Equipped with different attachments, it can carry out bulldozing, lifting and handling other materials.
FD15
FD15
It mainly shovels, loads, unloads and transports bulk materials like soil and stones.
Rated Load: 1500 kg
Operating Weight: 3000 kg
Bucket Capacity: 0.8 m³
Bucket Width: 1.8 m
Travel Speed: 30 mph
Fuel Tank Capacity: 60 L
Hydraulic Oil Tank Capacity: 60 L
Boom Thickness: 25 mm
Product Description
It mainly shovels, loads, unloads and transports bulk materials like soil and stones. It also conducts light excavation on rocks and hard soil. Equipped with different attachments, it can carry out bulldozing, lifting and handling other materials.
Product Data
| Parameter | Specification |
| Rated Load | 1500 kg |
| Operating Weight | 3000 kg |
| Bucket Capacity | 0.8 m³ |
| Bucket Width | 1.8 m |
| Travel Speed | 30 mph |
| Fuel Tank Capacity | 60 L |
| Hydraulic Oil Tank Capacity | 60 L |
| Boom Thickness | 25 mm |
| Dump Height | 3200 mm |
| Track Width | 1670 mm |
| Wheelbase | 2200 mm |
| Maximum Steering Angle | ±30° |
| Gradeability | 30° |
| Minimum Ground Clearance | 260 mm |
| Overall Dimensions | 5300 × 1800 × 2600 mm |
| Engine Model | 490 |
| Power | 42 kW |
| Number of Cylinders | 4 |
| Transmission | 265 Transmission (split-type optional) |
| Drive Axle | Small Hub-reduction Axle |
| Brake Type | Air Brake |
| Tire Size | 20.5/70-16 |
